Unique 100% Italian design
Unico windows and French windows have an iconic, on-trend design. They are able to add a superior aesthetic touch and excellent performance in terms of insulation, as well as burglar-proof qualities, thanks to the combination of PVC with galvanised steel reinforcements. The square-cut linear profiles, thanks to their rounded glass holders, cut to 45°, mean that we can create unique designs.
QUALITY DETAILS
Galvanised steel reinforcements for improved insulation and security
With the combination of PVC and galvanized steel reinforcements, the Unico system offers all-round protection to interiors of all types. With a casement rebate of just 9 mm, Unico windows and French windows have simplified design to optimise spaces. They have no aluminium sill, but they do have front drainage holes shaped to allow rainwater to flow off with creating any damage. Unico has ROTO NX Sil level 6” hardware based on the tried and tested “NT” system, but more efficient and secure, with added comfort and more resistance to corrosion.
Strength and robustness
Resists thermal and mechanical stress.
Fastening cap
Covers the screws used for fastening.
Vent
This hides the unsightly top vents in the frame.
Technical characteristics
- 6 chambers with a construction depth of 76mm
- Double rabbet seal + central seal
- Galvanised steel reinforcements with a thickness of notable dimensions
- Welded seal on slanted joints
- Certified, high-level heat and sound insulation with Warm Edge duct
- Possibility to use double glazing up to 60 mm thick
- Glass-casement bonding with special foam for improved structure and sound insulation
- Roto NX, burglar-proof metal hardware with bottom hung casement as standard for the correct ventilation of the room
- Product 100% Made in Italy
- 100% recyclable
MULLION THERMAL TRANSMITTANCE
Uf = 1,10 W/m2K
GLASS THERMAL TRANSMITTANCE
Uf = 1,10 W/m2K
OVERALL THERMAL TRANSMITTANCE
Uf = 1,24 W/m2K
AVAILABLE COLOURS
BATCH COLOURS
-
Bianco 3
TYPE A COATING
-
Ciliegio 110
-
Noce 154
-
Bianco classico 100
-
Crema 96
-
Cedro sbiancato 694
-
Grigio Antracite liscio 048
