PVC WINDOWS

BRILLET

Excellence, made in Italy

Aesthetic and performance in a single system, with ThermoFibra and Forthex

Brillet windows and French windows are an intelligent way to revolutionise the PVC door and window industry: you’ll find all of the latest industry innovations in a single system. Brillet is an elegant window with minimalist design, thanks to a casement rebate of just 7 mm. Another essential aspect is sustainability, since Brillet is 100% recyclable.

ThermoFibra profiles
For excellent mechanical and thermal resistance.

Wide range of available colours
This means you can always find the best possible solution for your home.

Casement with just a 7mm rebate
Guaranteed lightweight window design.

Aluminium sill
Eliminates the drainage holes at the front with the relevant cap.

Vent
This hides the unsightly top vents in the frame.

Fastening cap
Covers the screws used for fastening.

Technical characteristics

  • 6 chambers with a construction depth of 76mm
  • Double rabbet seal + central seal
  • Welded seal on slanted joints
  • Certified double glazing with excellent heat and sound insulation and Warm Edge duct + Gas Argon 90%
  • Glass-casement bonding with special foam for improved structure and sound insulation
  • Possibility to use double glazing up to 60 mm thick
  • Roto NX, burglar-proof metal hardware with bottom hung casement and microventilation as standard for the correct ventilation of the room
  • Product 100% Made in Italy
  • 100% recyclable

FRAME AND CASEMENT SECTION THERMAL TRANSMITTANCE

Uf = 0,85 W/m2K

GLASS THERMAL TRANSMITTANCE

Ug = 1,10 W/m2K

OVERALL THERMAL TRANSMITTANCE

Uw = 1,15 W/m2K

Download technical data sheet

AVAILABLE COLOURS

BATCH COLOURS

  • Bianco 3

  • Avorio 096

TYPE A COATING

  • Ciliegio 110

  • Noce 154

  • Bianco classico 100

  • Crema 96

  • Cedro sbiancato 694

  • Grigio Cedro 143

  • Grigio 004

  • Verde scuro 006

  • Grigio Antracite liscio 048

  • Grigio Quarzo 068

  • Grigio Antracite 072

  • Blu Acciaio 079

  • Winchester 109

  • Bronzo scuro 138

  • Macore 144

  • Alluminio Grigio 184

  • Douglas 402

  • Grigio Basalto liscio 628

  • Grigio liscio 651

  • Alux DB703 653

  • Noce Sorrento Balsamico 663

  • Grigio Basalto 667

  • Grigio Antracite Stylo 686

  • Nero Grafite Stylo 690

  • Grigio Chiaro 907

  • Alluminio liscio 911

  • Alluminio Bianco 925

  • Marrone Cioccolato 008

TYPE B COATING

  • Rosso scuro 027

  • Nero Grafite Matt 043

  • Grigio Ombra Matt 044

  • Woodec Turner Oak Matt 047

  • Grigio Antracite Matt 103

  • Bronzo spazzolato 119

  • Verde Muschio 134

  • Bianco Matt 358

  • Woodec Turner Oak Toffee 1342

  • Woodec Turner Oak Walnut 1346

  • Woodec Sheffield Oak Concrete 1036

  • Woodec Sheffield Oak Alphine 1042

A design choice

Brillet also brings innovation at aesthetic levels. When we developed Brillet we paid the same care and attention to the aesthetic details that we used to define the technical characteristics, in line with the latest market trends. Doors and windows are a lasting asset and play an essential part in the visual harmony of a building. This is why we took the different design and style needs of architects and professionals into account.

The construction profile

The PVC profile stands out for the number and layout of the chambers used to make it. According to the number of chambers, this changes the flow of heat from inside to out: more chambers means improved heat insulation. Brillet consists of 6 chambers with a construction depth of 76 mm. With suitable glazing, it is possible to achieve Uw values of 0,77 W/m2K.
